Sinotec 550w Solar Panel | 17.1kW PV

$6,800.00
Save $0

Free shipping (lower 48 states)

Sinotec Solar 550W Bifacial Panel 550W dual-glass mono PERC module Up to 25% rear-side power gain Anti-reflective, self-cleaning glass surface Certified for wind, sand, and salt corrosion 25-year product & 30-year performance warranty
Product Model

Choose a configuration below.


Quantity
Title

Total Price

           Total Price

$6,800.00

Equipment-only bundle. Licensed installation required per NEC & local AHJ. Improper installation may void warranty. Disclaimer — Installation & Safety Policy (PDF).

Build Your Own Bundle

Custom your own solar + storage bundle

Submit your requirements and we'll provide you with a tailored solution.

Overview

Title

Tech Specs

Title
550W Monocrystalline PERC Solar Panels
Peak Power 550W
Solar Cell Mono Bi-Facial
Product Tolerance ±3%
Module Efficiency(%) 21.3%
Maximum Power Current(IMP) 13.12A
Maximum Power Voltage(VMP) 41.95V
Short Circuit Current(ISE) 14.47A
Open Circuit Voltage(VOC) 50.41V
Maximum System Voltage 1500VDC(IEC)
Landscape 1400mm ,4 mm²/12 AWG
Front cover 3.2 mm high transparency, AR coating, thermal reinforced glass
Connector MC Compatible / MC4-EVO2 (optional)
Junction box IP68, 3 diodes
Operating Temperature -40°C to +85°C
Dimension 2278x1134x35mm
Weight 28.5 ± 0.5kg
Warranty 25 Years
Certificate ROHS/EN61000-6-1/EC61000-6-3/FCC15 class B/EC62109-1/IEC62109-2/UL1741

Supports

Title

  • Download

  • Video

  • FAQ

User Manual
Warranty
Certifications
Sintec 550W Solar Panel Datasheet
