Sinotec 410w Solar Panel | 4.9-12.7kW PV

$1,800.00
Save $0

Free shipping (lower 48 states)

Sinotec Solar 410W Mono PERC Panel High-efficiency 410W monocrystalline half-cut design Excellent low-light and high-temperature performance Durable black frame, 5400 Pa snow / 2400 Pa wind load PID-free, corrosion and salt mist resistant 25-year product & performance warranty
Product Model

Choose a configuration below.


Quantity
Title

Total Price

           Total Price

$1,800.00

Equipment-only bundle. Licensed installation required per NEC & local AHJ. Improper installation may void warranty. Disclaimer — Installation & Safety Policy (PDF).

Build Your Own Bundle

Custom your own solar + storage bundle

Submit your requirements and we'll provide you with a tailored solution.

Overview

Title

Tech Specs

Title
410W Monocrystalline PERC Solar Panels
Peak Power 410W
Solar Cell Monocrystalline PERC 182*91mm
Product Tolerance ±3%
Module Efficiency(%) 21.00%
Maximum Power Current(IMP) 13.06A
Maximum Power Voltage(VMP) 31.4V
Short Circuit Current(ISE) 13.82A
Open Circuit Voltage(VOC) 37.6V
Landscape 1200mm (47.24inches)
Front cover 3.2mm (0.13inches) tempered glass with AR coating
Connector MC4 or MC4 compatible
Junction box IP68, 3 diodes
Operating Temperature -40°C to +85°C
Maximum System Voltage 1000V DC/1500V DC
Dimension 1722x1134x30mm
Weight 21.5kg
Warranty 25 Years
Certificate ROHS/EN61000-6-1/EC61000-6-3/FCC15 class B/EC62109-1/IEC62109-2/UL1741
